ICF blocks 8 inch core 45* Corner (9 pcs) Fox Blocks

Name: ICF blocks 8 inch core 45* Corner (9 pcs) Fox Blocks
Brand: Material Warehouse
SKU: FOX-EC845
Price: 533.09 USD
Availability: OutOfStock

by Material Warehouse

Sold out

$533.09

SKU FOX-EC845

Quantity

6-inch wide core, 45-degree angle corner - Fox Blocks (9 block bundle)

The 45 Degree Angle Block typically makes up less than 5% of the ICF wall assembly on most residential and commercial jobs.

To improve construction wall strength during installation, each course of blocks should have their end-joint connections staggered in a running bond method from the course adjacent to it.

Dimensions:

16" tall, 28" long, 20" Return, and 13.25" OD wide
48 square feet per unit bundle
Internal concrete volume 1.05 cu. yd/ 9 block bundle

View the entire Fox Block Catalog

Looking for a quote for your project? Fox Blocks Project Quote Form Here>

(800) 567-5358

Fox Blocks are sold in bundle quantities only.

8" Core 45 Corner Block

Product SKU: FOX-EC845
Dimensions: 16" Height 28" Long, 20" Return 13.25" OD Width
Model: 45 Corner Block - 8" Core Width

Need a written quote? Request Online
Questions? Call (800) 567-5358

R-Value = R-23
EPS foam material inhibits growth mold, mildew, and rot
Embedded Interlocking rebar saddle

ICF OVERVIEW

SHIPPING TIME

Call (800) 567-5358 for pricing and logistics questions

Fox Blocks are shipped from one of our US regional warehouses.

Will Call is available and encouraged for local pickup. Contact us to find out where the closest regional warehouse is for you.

Most orders ship out 5-8 business days following the order depending on stock levels. Lead time may vary depending on production levels and seasonality.

WAREHOUSE LOCATIONS

Regional ICF distribution warehouses

DOWNLOADS AND TECHNICAL INFO

Download Fox Blocks
Technical Info & Guidebook >Download Fox Blocks
Full Line Card >Download Technical
Performance Data >
Download Sizes Volumes
and weights >

BASEMENT PROJECT INSTALL 2MIN

45 DEGREE CORNER BLOCK ICF

45 degree Fox Blocks Corner ICF Block

corner blocks are reversible so when you ask for a corner you will get the correct one every time. E
Foam thickness is 2.625" on all forms.
Tie allows rebar lap splices to lay on top of each other for good flowability during concrete placement.
Ties touch vertically when stacked, eliminating form settlement.

THE FOX BLOCKS ADVANTAGE

All block have 2 5/8" EPS for consistent R-Value
Blocks are reversible to encourage easy installation
Rebar spacing is consistently 16" o/c and lower truss is 8" o/c from top or bottom of upper truss
All block work with each other, example the 4" block will connect to all sizes of block
Interlocking forms minimize movement during concrete placement
Interlocking forms minimize movement during concrete placement
No adhesive required in between forms due to the precision engineering of interlocking blocks
